N45SH High Performance NdFeB Magnets Airsoft Motor
Product Description
| Brand | CHIHAI MOTOR |
| Product Type | CHF-480Ultra-14TPA High Torque Large Silver Brush Airsoft Motor |
| sizes | 88.5x25x30mm(Includes shaft and gears) |
| Magnetic materials | N45SH temperature resistant NdFeB magnet |
| DC11.1V SPEED | 38000 rpm |
| DC7.4V SPEED | 25000 rpm |
| weight | About 140g |
N45SH temperature resistant NdFeB magnet:
Ensures constant and stable torque output high durability and not easy to demagnetize.
Ball bearing construction:
The front cover and bushing are processed in one piece, including two ball bearings.
CNC machined back cover with one ball bearing inside
CNC aluminum alloy front and rear covers:
CNC high-precision specifications ensure protection
The aluminum alloy shell has stronger heat dissipation, rigidity and durability.
MIM injection steel cut bevel gear:
Hardened, stable and durable for longer life.
Detailed Images
Product Paramenters
| Model：CHF-480Ultra-14TPA High performance NdFeB magnets Motor |
| Voltage:DC 11.1V CCW |
| No Ioad speed | No Ioad current | At stall torque | At stall torque |
| 38000 rpm | 4.30 A | 471.2 mN.m | 176.82 A |
| At max efficiency |
| Effi | Torque | Speed | Current | Output Powe |
| 71.54 % | 63.57 mN.m | 32874 rpm | 27.57 A | 219.0 W |
| At max output power |
| Effi | Torque | Speed | Current | Output Powe |
| 46.66 % | 235.6 mN.m | 19000 rpm | 90.56 A | 469.05 W |
