Permanent Magnet Brush Holzer Magnetic Encoder Motor
Product Description： Product Paramenters
Send Inquiry
Product Description：
| Brand | chihai motor |
| Model | CHR-775S permanent magnet brush Holzer magnetic encoder motor |
| external diameter | Φ42mm×82.5mm |
| Shaft diameter | Φ5.0mm |
| Shaft length | 15mm Circular shaft |
| Rated Voltage | DC 12-24V |
| Encoder type | Incremental magnetic encoder |
| Hall code interface type | PH2.0-4PIN Standard connection terminal line,wire length 200mm |
| Motor power interface type | VH3.96-2PIN Standard wiring wire length 200mm |
| Weight | About 383g |
Product Paramenters
| Model：CHR-775S permanent magnet brush Holzer magnetic encoder motor | ||
| DC24.0V MAX Power110W | ||
| USE Voltage: | DC 12.0V |
DC 24.0V |
| Direction of rotation | CW/CCW | |
| No-load speed (rpm) | 4100 | 8200 |
| No-load current (A) | 0.45 A MAX | 0.55 A MAX |
| Rated torque (g.cm) | 400 | 800 |
| Rated speed (rpm) | 3200 | 7000 |
| Rated current (A) | 2.5 A MAX | 3.5 A MAX |
| Stall torque (kg.cm) | ≥2.2 | ≥5.0 |
| Stall current (A) | ≤12.0 | ≤25.0 |
| Start voltage |
DC 3.0V |
|
