GM25-BK370 Hall Encoder DC Gear Motor
Product Description
| Product Type |
CHR-GM25-BK370-ABHL dc gear reducer encoder motor |
| Motor diameter | Φ25mm |
| Shaft length | 12mm D 8mm |
| Voltage | DC 1.5-12V (customized in batches) |
| Weight | About 97g |
| Wiring specification | PH2.0 (Standard wiring) |
| Encoder specifications |
AB dual phase encoder 11 line basic signal voltage 3.3V or 5.0V |
| Application |
Intelligent self-balancing two-wheeled car, intelligent home appliances,Robot, camera rocker arm, electric paper cutter, etc |
Dc coding motor is one of the most commonly used motors in modern industry, which can not only meet the needs of industrial production, but also improve production efficiency. Dc coding motor has the advantages of high efficiency, high precision, flexible speed adjustment, etc., and is widely used in various industrial fields.
The control system of DC coding motor can realize automatic control, which greatly improves productivity and reduces the waste of human resources. At the same time, due to the small size and light weight of the DC coded motor, it is very convenient to install and maintain, which can save time and cost.
In addition, the DC code motor also has durability and reliability, can withstand load and environmental changes, to ensure the stability and quality of production. The motor has a long service life and does not require frequent replacement.
Detailed Images
Product & specifications
| Model：CHR-GM25-BK370-ABHL DC gear reducer encoder motor |
| Special note: Due to the high power and high current of the motor, all customers must have a power supply of 10A or more. |
| Voltage:DC6.0V max power 8.0W Input motor speed 10000RPM |
| RATIO | 1:4.4 | 1:9.3 | 1:20 | 1:34 | 1:45 | 1:57 | 1:75 | 1:100 | 1:125 | 1:217 | 1:478 |
| No-load current(mA) | ≤400 | ≤400 | ≤400 | ≤400 | ≤400 | ≤400 | ≤400 | ≤400 | ≤400 | ≤400 | ≤400 |
| No-load speed(rpm) | 2000 | 880 | 440 | 259 | 195 | 154 | 117 | 88 | 70 | 40 | 18 |
| Rated torque(Kg.cm) | 0.3 | 0.60 | 1.2 | 2.0 | 2.7 | 3.5 | 4.5 | 6.0 | can't exceed 8.0kg.cm(0.8N.m) | ||
| Rated torque(N.m) | 0.03 | 0.06 | 0.12 | 0.20 | 0.27 | 0.34 | 0.44 | 0.59 | |||
| Rated speed(rpm) | 1500 | 660 | 330 | 194 | 147 | 116 | 88 | 66 | 53 | 30 | 14 |
| Rated current(A) | ≤1.4 | ≤1.4 | ≤1.4 | ≤1.4 | ≤1.4 | ≤1.4 | ≤1.4 | ≤1.4 | ≤1.4 | ≤1.4 | ≤1.4 |
| Stall current(A) | ≤8.0 | ≤8.0 | ≤8.0 | ≤8.0 | ≤8.0 | ≤8.0 | ≤8.0 | ≤8.0 | ≤8.0 | ≤8.0 | ≤8.0 |
| Stall torque(kg.cm) | ≥1.5 | ≥2.5 | ≥5.0 | ≥7.0 | ≥8.0 | can't exceed 9.0 kg.cm | |||||
| length of gearbox(L) | 19 | 19 | 19 | 21.5 | 24 | 24 | 26.5 | 26.5 | 29 | 29 | 29 |
| Hall signal | 48.4 | 102.3 | 220 | 374 | 495 | 627 | 825 | 1100 | 1361.8 | 2387 | 5258 |
| Voltage:DC12.0V max power 26W Input motor speed 20000RPM |
| RATIO | 1:4.4 | 1:9.3 | 1:20 | 1:34 | 1:45 | 1:57 | 1:75 | 1:100 | 1:125 | 1:217 | 1:478 |
| No-load current(mA) | ≤600 | ≤600 | ≤600 | ≤600 | ≤600 | ≤600 | ≤600 | ≤600 | ≤600 | ≤600 | ≤600 |
| No-load speed(rpm) | 4300 | 1892 | 946 | 556 | 420 | 332 | 252 | 189 | 151 | 87 | 40 |
| Rated torque(Kg.cm) | 0.5 | 1.1 | 2.3 | 3.50 | 4.50 | 6.00 | 7.00 | can't exceed 8.0kg.cm(0.8N.m) |
|||
| Rated torque(N.m) | 0.05 | 0.10 | 0.21 | 0.34 | 0.44 | 0.59 | 0.69 | ||||
| Rated speed(rpm) | 3300 | 1452 | 726 | 427 | 323 | 255 | 194 | 145 | 116 | 67 | 30 |
| Rated current(A) | ≤2.7 | ≤2.7 | ≤2.7 | ≤2.7 | ≤2.7 | ≤2.7 | ≤2.7 | ≤2.7 | ≤2.7 | ≤2.7 | ≤2.7 |
| Stall current(A) | ≤16.0 | ≤16.0 | ≤16.0 | ≤16.0 | ≤16.0 | ≤16.0 | ≤16.0 | ≤16.0 | ≤16.0 | ≤16.0 | ≤16.0 |
| Stall torque(kg.cm) | ≥0.8 | ≥1.3 | ≥2.5 | ≥3.5 | ≥4.5 | ≥6.0 | ≥8.0 | can't exceed 9.0 kg.cm | |||
Packing & Delivery
PACKAGE:
Standard export carton packing.
DELIVERY TIME:
3-20 days after confirming order,detail delivery date should be decided according to
production season and order quantity.
ATTENTION:
If special customs clearance documents are required, please contact us in advance for confirmation.
