N35 Ndfeb Fire Control High Torque Motor
Product Description
| Product Type | CHF-480WA-7516G-57.5D HIGH Torque Motor |
| Appearance |
Shell paint/CNC Aluminum Alloy Cover |
| Magnetic materials | Nd-Fe-B Magnet |
| DC11.1V SPEED | 333000 rpm |
| weight |
About 151g |
| Adaptation type |
Ver.2 gearbox Airsoft gun JIN MING M4A1-J9 Airsoft gun JIN MING M4A1-J9 ACR-J10 Wavebox upgrade 480 motor insertion Special wave box type: WARINTEREST JIQU HK416D / KUBLAI BD556 JINGJI SLR / NEW WELL M4 FB WAVE BOX FIGHTING BRO |
Features:
1-N35 Neodymium Magnet
2- PPS Heat-resistant back cover
3-Ball bearing construction
4- MIM steel pinion gear
5-High heat dissipation paint case
6-High performance wear-resistant carbon brush
7-Armature Dynamic Balancing
8-Support fire control chip
Detailed Images
Product Parameters
| Model：CHF-480WA-7516G-57.5D HIGH Torque Motor |
| Voltage: DC 11.1V |
| No load speed | No load current | At stall Torque | At stall Current |
| 33000 rpm | 3.30 A | 376.2 mN.m | 120.12 A |
AT MAX EFFICIENCY
| Speed | Current | Torque | Output Powe | Efficiency |
| 28308 rpm | 19.91 A | 53.49 mN.m | 158.7 W | 71.79302 % |
AT MAX OUTPUT POWER
| Speed | Current | Torque | Output Powe | Efficiency |
| 16500 rpm | 61.71 A | 188.1 mN.m | 325.2147 W | 47.47 % |
Packing & Delivery
PACKAGE:
Standard export carton packing.
DELIVERY TIME:
3-20 days after confirming order,detail delivery date should be decided according to
production season and order quantity.
ATTENTION:
If special customs clearance documents are required, please contact us in advance for confirmation.
